Leading Wafer Butterfly Valve Manufacturer In India

Introduction

Masterpiece Group manufactures high-performance Wafer Butterfly Valves in India, engineered for reliable shutoff and throttling across marine systems, HVAC, water treatment, fire mains, and general industry. Our wafer type butterfly valves are built to international standards, offering long service life and low torque operation. We are committed to delivering superior quality and ensuring complete customer satisfaction.

We supply DN50–DN600 in PN10/PN16/PN25 with EPDM/NBR/PTFE/Viton seats. Material options include ductile iron (DI), WCB, CF8/CF8M stainless steel, and aluminum bronze for seawater service. For buyers searching for a wafer butterfly valve price or a detailed price list in India, we provide transparent guidance and rapid quotations.

We are a leading Wafer Butterfly Valve, Wafer butterfly valve price, Wafer butterfly valve price in India, Wafer type butterfly valve, Stainless steel wafer butterfly valve, Ductile iron wafer butterfly valve, EPDM seat wafer butterfly valve, PTFE seat wafer butterfly valve, Gear operated wafer butterfly valve, Lever operated wafer butterfly valve, Pneumatic actuated wafer butterfly valve, Electric actuated wafer butterfly valve, API 609, EN 593, ISO 5752, EN 558, ISO 5211, MSS SP-67, EN 12266-1, PN10, PN16, PN25, DN50, DN600, Marine, HVAC, Water treatment.

What is a Wafer Butterfly Valve?

A wafer butterfly valve is a compact, lightweight flow control valve that mounts between flanges (PN10/PN16 or ASME Class 150). The central disc rotates via a shaft to open/close the flow, with resilient seats ensuring bubble-tight shutoff. Its design simplifies installation, reduces footprint, and offers excellent cost-performance.

Materials & Standards

Our wafer butterfly valves are manufactured using high-grade materials and adhere to stringent international standards, ensuring durability and optimal performance in diverse applications.

• Body: Ductile Iron (DI), WCB (Carbon Steel), CF8/CF8M (Stainless Steel), Aluminum Bronze (Marine). These materials are selected for their corrosion resistance and mechanical strength.
• Disc: DI/Ni-plated, CF8/CF8M, Aluminum Bronze (Sea water). Discs are precision-machined for optimal flow control and sealing.
• Shaft: SS 410/SS 304/SS 316. High-strength stainless steel shafts ensure reliable operation and resistance to wear.
• Seat/Liner: EPDM, NBR, PTFE, Viton (service-dependent). Resilient seats provide bubble-tight shutoff and chemical compatibility for various media.
• Standards: Adherence to API 609 (Butterfly Valves: Double Flanged, Lug- and Wafer-Type), EN 593 (Industrial valves – Metallic butterfly valves), ISO 5752/EN 558 (Face-to-face and centre-to-face dimensions of metal valves for use in flanged pipe systems), IS flange drillings and ASME Class 150 compatibility ensures interchangeability and global acceptance.
• Actuator Interface: ISO 5211 top flange for direct mounting of gearboxes and actuators, providing versatile automation options.
• Design Practice: MSS SP‑67 (Butterfly Valves) for butterfly valve geometry and performance, guaranteeing robust design.
• Coatings: Fusion-bonded epoxy (FBE) or marine-grade coatings for superior corrosion resistance in harsh environments.
• Testing: EN 12266‑1 (Industrial valves – Testing of metallic valves – Pressure tests, test procedures and acceptance criteria – Part 1: Pressure tests, test procedures and acceptance criteria for the industrial valves specified in the European Standards) hydrostatic (body/seat) with zero visible leakage for resilient seats, ensuring leak-proof operation.

Certifications and Approvals

Masterpiece Group's wafer butterfly valves are backed by various certifications and approvals, demonstrating our commitment to quality and compliance with industry regulations. These include:

• ISO 9001:2015 Certified: Our quality management system ensures consistent product quality and customer satisfaction.
• DNV, IRS, ABS Approved: For marine applications, our valves meet the stringent requirements of leading classification societies.
• CE Marking: Compliance with European health, safety, and environmental protection standards.
• PED (Pressure Equipment Directive) Compliant: Ensuring safety for pressure equipment within the European Union.

Applications

• Marine sea water lines, cooling, ballast, and firefighting mains
• HVAC chilled and cooling water circuits
• Water treatment and distribution networks
• Industrial process lines, chemical, and general utility services
• Pump suction/discharge isolation and throttling

Key Features & Specifications

• Size Range: DN50 – DN600 (larger on request)
• Pressure Ratings: PN10 / PN16 / PN25
• End Connection: Wafer, fits PN10/PN16 and ASME Class 150 flanges
• Operation: Lever, gear operator, or actuation-ready (pneumatic/electric)
• Seat Options: EPDM/NBR/PTFE/Viton to suit media and temperature
• Temperature Range: -10°C to 200°C depending on seat/materials
• Face-to-Face: ISO 5752 / EN 558 compliant for interchangeability
• Leakage Class: EN 12266‑1 Rate A (bubble‑tight) for resilient seats
• Documentation: MTCs, hydrostatic test reports, and compliance certificates (third‑party witness available)
• Pricing Note: See Pricing & Availability for wafer butterfly valve price guidance (size/material/seat dependent)

Manufacturing & Fabrication

1. Body & Disc Casting: Controlled metallurgy for mechanical strength and corrosion resistance
2. Precision Machining: Tight tolerances for face-to-face, shaft seats, and disc edges
3. Seat/Liner Installation: Resilient seats fitted for bubble-tight shutoff
4. Assembly: Shafts, bushings, and seals assembled with alignment checks
5. Coating: FBE/marine coatings applied per service requirements
6. Testing: Shell pressure, seat leakage, and functional torque tests

Quality Assurance & Testing

• Shell Test: Verifies body integrity under rated pressure
• Seat Leakage Test: Ensures bubble-tight shutoff per API 609/EN 12266
• Operational Torque: Confirms smooth actuation and sealing performance
• Dimensional Checks: Face-to-face, flange compatibility, and alignment
• NDT (as required): DP/UT on critical components for high-reliability applications

Service Coverage in India

• Major Ports: Mumbai, Chennai, Kolkata, Kochi, Visakhapatnam, Kandla, Paradip
• Industrial Hubs: Pune, Kolhapur, Ahmedabad, Bangalore, Hyderabad
• States: Maharashtra, Gujarat, Tamil Nadu, Kerala, Goa, Andhra Pradesh, Odisha, West Bengal

We provide rapid delivery with local technical support and spares availability.

Installation & Maintenance

• Verify flange alignment and gasket selection; ensure correct face-to-face fit
• Use recommended bolt torque sequence; re-check after initial runs
• Inspect seats and shafts periodically; clean deposits to maintain sealing
• Record service conditions to plan preventive maintenance

Why Masterpiece Group

• Compliance with API 609/EN 593 and marine class requirements
• Custom materials, seat options, and actuation configurations
• Integrated manufacturing and rigorous QA for consistent performance
• Reliable after-sales support with quick spares turnaround

People also searched for

Wafer Butterfly Valve, Wafer butterfly valve price, Wafer butterfly valve price in India, Wafer type butterfly valve, Stainless steel wafer butterfly valve, Ductile iron wafer butterfly valve, EPDM seat wafer butterfly valve, PTFE seat wafer butterfly valve, Gear operated wafer butterfly valve, Lever operated wafer butterfly valve, Pneumatic actuated wafer butterfly valve, Electric actuated wafer butterfly valve, API 609, EN 593, ISO 5752, EN 558, ISO 5211, MSS SP-67, EN 12266-1, PN10, PN16, PN25, DN50, DN600, Marine, HVAC, Water treatment.

Conclusion

For dependable Wafer Butterfly Valves engineered in India to international standards, Masterpiece Group delivers quality, speed, and support. Contact us for specifications, drawings, and a tailored quotation.
